Standards

ASTM D4595, BS EN ISO 10319, EN ISO 12236(GB/T14800), ASTM D4833, ASTM D5034, ASTM D5035, ASTM D-4533, BS6906.1,GB/T16989



Features

1. Smart touch interface, 5.7-inch super large screen, click at will.
2. The load cell adopts a 0.5-level high-precision load cell.
3. Adopt the international high-end all-aluminum alloy shape design, and the surface is treated with sandblasting and anodizing process.
4. The Chinese and English dual interface can be switched arbitrarily, and the test curve, graph, and data can be displayed dynamically.
5. Adopt advanced digital signal processing (DSP) technology, Philips 32-bit full digital control and 2500 f/s high-speed data acquisition.
6. Taiwan precision pre-loaded ball screw, no backlash, high positioning accuracy.
7. Non-clutch drive device, capable of running at full speed under maximum force.
8. Fully comply with “Mechanical Equipment 2006/42/EC”, “Low Voltage 2006/95/EC”, “EMC Directive 20044/108/EC” and GOST-R;



Technical specifications

Model	GT-010	GT010D
Test method & Control	CRE principle, microcomputer control, LCD display, support for online	CRE principle, microcomputer & computer dual control, dual-screen display
Test load	5KN;10KN; 30KN; 50KN
Sampling frequency	2500hz	2500hz
Measuring force range	1%~100% of full scale	1%~100% of full scale
Force measurement accuracy	≤±0.02%F.S	≤±0.02%F.S
Stretching speed	0.05-500mm/min	0.05-500mm/min
Effective stroke of beam	800mm Resolution: 0.01mm	800mm Resolution: 0.01mm
Holder: wide strip tensile test	width 200mm; tear test: width 100mm	width 200mm; tear test: width 100mm
CBR burst test	φ50×100mm	φ50×100mm
Power supply:	AC220V±10% 50Hz 1.5KW	AC220V±10% 50Hz 1.5KW
Dimensions	860×600×1800mm	860×600×1800mm
Weight	300kg	320kg





Applicable tests

Tests type	Suggested load	Test parameters	Standards
1.Wide-width tensile & elongation	10000N 50000N	1. Clamper width: 220mm Sample width: 200mm 2. Clamp distance: 100mm	BS EN ISO 10319
2.Trapezoidal Tear test			ASTM D-4533
3.CBR puncture test	50000N	1. Mandrel Dia.: 50mm Circular clamper inner dia.: 150mm sample dia.:230mm 2. Press rate: 60mm/min	EN ISO 12236(GB/T14800)
4.Puncturing test	10000N	1. Mandrel diameter: 8mm Inner diameter of ring fixture: 44.5mm Sample diameter: 120mm 2. Pressing speed: 30mm/min	GB/T17643, ASTM D4833
5. Breaking force and elongation strength test	10000N 50000N	1. Width of holder: 25mm Sample width: 100mm 2. Stretching speed: 100mm/min 3. Clamping distance: 75mm	ASTM D5034, D5035
