Civil engineering & Material Testing equipments

2000KN Servo control Hydraulic universal testing machine

Model: UTM-2000D

Technical specifications

Max testing force 2000kN
Accuracy degree 0.5(0.5%)
Test force measuring range 0.4%-100%, stepless, equivalent 4 steps
Force indication value relative error ＜±0.5%
Test load resolution 1/500000
Deformation indication value relative accuracy ＜±0.5%
Deformation resolution 1/300000
Max tensile test space 1100mm
Compression space 950mm
Piston stroke 300mm
Cylinder sample max clamping range Φ20mm-Φ90mm
Flat sample max clamping thickness 0-70mm
Flat sample max clamping width 140mm
Platen size Φ300mm, HRC>55
Clamping mode Hydraulic
Main machine overall size L1200mm×W850mm×H3400mm
Controller size 1100mm×750mm×1000mm
Motor total power 4.5KW
Net weight 9000KG
